Pixel pitch：1.9/2.6（Indoor）;2.9/3.9(Outdoor)
Cabinet Size：500*500/1000mm
The RP Series LED display is engineered for indoor and outdoor stage events, rental applications, and exhibitions. It features high-thrust 2-in-1 lamp beads with a 13kg load capacity, a 400% increase over traditional 3kg modules. Four-layer protection—including micro-brim, anti-collision bosses, module corner guards, and soft rubber corners—ensures long-lasting durability. Non-GOB packaging reduces glare, provides a wider viewing angle, and delivers sharper visuals. Flexible splicing allows curved, right-angle, and compatible connections with RAS Series cabinets. Chamfered socket design improves waterproof performance, and optional dual-signal input ensures uninterrupted transmission. Quick-lock and modular designs simplify installation and maintenance.
Pixel pitch：1.9/2.6/3.91
Cabinet Size：500*500mm
The RC Series is ideal for stage performances, rental projects, and exhibition displays. Four-layer protection includes thickened solder, micro-brim, aluminum corner guards, and PCB copper reinforcement. Quick, single-person installation improves efficiency by 40%. Front and rear maintenance simplifies inspections, while curved lock splicing allows angles from -5° to +10° and compatibility with multiple cabinet sizes. Chamfered socket design enhances waterproofing, and optional dual-signal input ensures uninterrupted transmission. Modular and soft-rubber corner guards provide additional impact resistance.
Pixel pitch：2.6 / 2.9
Cabinet Size：500*500mm
The RAS Series supports creative stage design, exhibitions, and rental applications with cylindrical, concave, convex, or S-shaped splicing. Flexible locks allow precise angle adjustment up to +30° and compatibility with other rental cabinets. Four-layer protection includes thickened solder, micro-brim, soft rubber corner guards, and PCB copper reinforcement. Single-strip modules improve water resistance and durability. Modular design enables rapid replacement, and aluminum alloy protection frames increase resistance to impact and drops.
Pixel pitch：3.9/4.8
Cabinet Size：500*500/750/1000mm
The FS-QM Series is ideal for outdoor advertising, sports arenas, and public spaces. With a maximum brightness of 10,000 cd/m² and contrast ratio of 15,000:1, images remain clear even under direct sunlight. The ultra-high refresh rate of ≥7680Hz ensures smooth video playback and camera-friendly recording. Multi-stage, fanless heat dissipation improves long-term stability while reducing failure rates. Dual-voltage link drive saves up to 30% power consumption. Heavy-duty spring latches enable quick installation, and front & rear maintenance is supported. Aluminum-plastic bottom shell and high bezel design reduce light decay.
